Module Size/Weight |
Size |
Width |
277 mm (10-29/32 inches) |
Height |
213 mm (8-25/64 inches) |
Deep |
95 mm (2-3/4 inches) |
Weight |
Weight |
1.5 kg (3.31 lbs) |
Tone generator |
Maximum polyphony |
64 notes |
Voice |
Drums and percussion: 1,268, Melodies: 128 |
Variations |
Reverb: 6, Chorus: 6, Variation: 42, Kit EQ: 4 bands, Master EQ: 3 bands |
Drum set |
Preset: 50, User: 10 * all of which may be edited and overwritten |
Music mixer |
Note capacity |
Approx. 152,000 notes |
Note resolution |
480 ppq (parts per quarter note) |
Type of song recording |
Real-time replacement |
Track songs |
1 track |
Song |
Demo: 2, Practice: 44, Pad: 17, User: 30 * all of which may be edited and overwritten |
Mix format |
Proprietary, SMF format 0 |
Tempo |
30 to 300 BPM, Tap Tempo supported. |
Beat |
1/4 to 4/16, 1/8 to 8/16, 1/16 to 16/16 |
Timing |
Accents, Quarter notes, Eighth notes, Sixteenth notes, Triplets |
Training function |
Measure break, Groove check, Rhythm gate |
Other |
Connector head |
USB TO DEVICE/TO HOST, OUTPUT [L/MONO] (Standard mono phone), OUTPUT [R] (Standard mono phone), Trigger Input 1 to 8, 11 (Standard stereo phone, L: Trigger Input, R: Rim Switch ), Trigger Input 9 and 10 (Standard stereo phone, L: Trigger Input, R: Trigger Input), HH-KICK (Standard stereo phone), HI-HAT CONTROL (Standard stereo phone), AUX IN (Stereo Mini), PHONES (Standard stereo phone), MIDI IN/OUT |
Accessory |
Power Adapter (PA-150, or an equivalent), Module holder, Module holder fastening screws x 4, Owner's Manual, Data List, DVD-ROM (Cubase AI) |
Enter Audio |
Sample |
500 |
Sample data bits |
16 bits |
Mono/Stereo sampling time |
44.1kHz: 23 sec, 22.05kHz: 46 sec, 11.025kHz: 1 min. 32 sec, 5.5125kHz: 3 min. 4 sec. |
Sample format |
WAV, AIFF |
